  • OAuth 2.0 Flow – A Metaphor

    The following video helps explain the OAuth 2.0 Flow and authorization. This video was originally shared as part of a prior project on Social Application Development.

  • Swagger Enumerations in YAML

    Recently, I have been spending time looking at the Swagger 2.0 Specification.  There XML representation and Enumerations are tricky.  Here is an example of a Swagger Enumeration in YAML.

    You can test the YAML at http://petstore.swagger.io/#!/default/get_demo

  • Raspberry Pi – Part IV – Simple Wiring Test

    I am plugging away working with my Pi. I went back to the Ada Fruit Site, and started working on one of the tutorials from the part I purchased – https://www.adafruit.com/products/2125   I want to be able to demonstrate a simple wiring with my Pi works.

    I selected Email Notifier. I read through it, and realized I needed to convert it to work for the B+ model. The pi4j website has a nice diagram for the pins http://pi4j.com/images/j8header-b-plus-large.png and I simplified the test a bit.

    I launched the simple python file

    pi@seconds ~ $ sudo python testPi.py

    Pi with a Green Light - Using Python
    Pi with a Green Light – Using Python

    I added the pi4j dependency to my maven pom

    <dependency>
        <groupId>com.pi4j</groupId>
        <artifactId>pi4j-core</artifactId>
       <version>1.0</version>
    </dependency>

    I create a servlet which replicated the same code from before (GPIO).

    I copied the war file to the local webapp directory, and restarted jetty

    pi@seconds /opt/jetty/web/bbq/webapps $ sudo cp ~/pi.webapp.war ./
    pi@seconds /opt/jetty/web/bbq/webapps $ sudo chown jetty:jetty pi.webapp.war
    pi@seconds /opt/jetty/web/bbq/webapps $ sudo /etc/init.d/jetty restart

    Refer to https://wiki.eclipse.org/Jetty/Howto/Deploy_Web_Applications  and I did have to add –module=jsp to the start.ini for my web configuration.

    I hit the servlet – http://192.168.1.200/pi.webapp/Control?status=true

    Exception
    Exception

    Which makes sense, since “Software using the Pi4J library must be run with ROOT level permissions.” (actually it doesn’t since I am running as root)…

    Issues remain.  I’ll tackle them on a different day 🙂   … Part 5 …

  • Raspberry Pi – Part III – Setting up Jetty

    The Raspberry Pi is a device that has so many options open: You can extend the hardware. You can extend the software. I choose to tackle extending the software to start, so I can get the experience that I want setup, and running on the device.  The experience I am after is the web interface to control my Raspberry Pi.

    For a Java developer, I conclude that a lightweight interface hosted on a Jetty server is probably easiest.  The Jetty server is a 12.9M download and 30M expanded. It’s also used frequently in devices, and why reinvent the wheel, use the approach that Industry is using.  Jetty is designed for a small memory footprint.   (I did consider using Tomcat Embedded, and came to the conclusion I’d probably want to many features.)

    I downloaded the Jetty archive to my local user’s directory. Note, since I want to just use jetty.zip I’m renaming the output file with wget -O.

    wget -O jetty.zip http://download.eclipse.org/jetty/stable-9/dist/jetty-distribution-9.2.10.v20150310.zip

    I make a directory for the application server, and move over jetty.zip to that directory.

    sudo mkdir -p /opt/jetty
    sudo mv jetty.zip /opt/jetty

    Next I launched into the sudoers root shell, and extract the Jetty archive.  I decided to move it into the runtime folder, so I can have an easy place to backup from.  (Remove the extra space from the .zip)

    sudo -s
    cd /opt/jetty
    unzip jetty.zip
    mv jetty-distribution-9.2.10.v20150310/ runtime
    rm jetty.zip

    Next, I wanted to setup Jetty as a service, and check that Jetty starts

    cp runtime/bin/jetty.sh /etc/init.d/jetty
    echo JETTY_HOME=`pwd`/runtime > /etc/default/jetty
    service jetty start
    Starting Jetty: . . . OK Sun Apr 12 15:38:40 UTC 2015
    service jetty stop
    Stopping Jetty: OK

    Next, I want to automatically start Jetty with the right runlevels

    update-rc.d jetty defaults

    I want to configure Jetty to run with a set user jetty.

    mkdir -p /opt/jetty/web/bbq
    mkdir -p /opt/jetty/temp
    useradd --user-group --shell /bin/false --home-dir /opt/jetty/temp jetty

    There is a base configuration that needs to be setup the base site.

    cd /opt/jetty/web/bbq
    java -jar /opt/jetty/runtime/start.jar --add-to-start=deploy,http,logging

    Next, edit the default port value.

    vi start.ini

    ## HTTP port to listen on
    jetty.port=80

    Finally, I wrap the configuration of the jetty service and app.

    chown -R jetty:jetty /opt/jetty
    echo "JETTY_HOME=/opt/jetty/runtime" > /etc/default/jetty
    echo "JETTY_BASE=/opt/jetty/web/bbq" >> /etc/default/jetty
    echo "TMPDIR=/opt/jetty/temp" >> /etc/default/jetty

    A good check is to look at service jetty status, and confirm the settings, and then restart your Raspberry Pi. I did find that the startup time was significantly effected by the additional service.  ( +25 seconds from the original 15)

    Navigate to http://192.168.1.200/ (or whatever IP you have used) and confirm the page loads Jetty.  If you see a 404, you’re off and ready for the next phase. (as am I) 🙂

    Jetty Starting Point
    Jetty Starting Point

  • Configure WLAN0 on Raspberry Pi

    I  don’t know how I did it.  I lost wireless connectivity, so I was forced to plugin my Raspberry Pi to the Lan.  Once, plugged in I could find it via the DHCP table on my router.

    I first checked the iwlist wlan0 scan to see if my home network was listed.  The home network was listed.  It was.

    I checked the wpa_supplicant configuration ~ $ sudo vi /etc/wpa_supplicant/wpa_supplicant.conf  and confirmed it pointed to the right network. I also checked dmesg to see if there were any hints for wpa_supplicant.

    I looked at the /etc/network/interfaces and found

    iface wlan0 inet manual

    which I converted to

    iface wlan0 inet dhcp

     Also wpa-debug-level 3 was very helpful and must proceed the wpa-roam statement in the interfaces.

    Also running the wpa_supplicant command can result in some good details

    pi@seconds ~ $ sudo wpa_supplicant -B -i wlan0 -c /etc/wpa_supplicant/wpa_supplicant.conf

    I also found this link helpful. https://wiki.debian.org/WiFi/HowToUse It showed how to reset manual to dhcp in the /etc/network/interfaces file

    Finally, I used http://weworkweplay.com/play/automatically-connect-a-raspberry-pi-to-a-wifi-network/ to finally review, and finally I broke down and set a static ip. Not sure why it won’t automatically take a dhcp configuration.

  • Raspberry Pi – Part II – Get Up and Going with Java

    In recent weeks, I haven’t revisited the Raspberry Pi – Running, Vacation, Work have conspired to keep me away from hobby project.

    I’ve stared at the parts long enough, and decide to plug the Raspberry Pi base into the wired network. I plugged in the Raspberry Pi into the Power outlet, and I got the Red Light.  I logged into my router to see if the Pi picked up the Raspberry Pi, and I found the IP from my routers IP reservations table.   I was able to SSH into the Pi and quickly check the release version ( cat issue ) – Raspbian GNU/Linux 7 \n \l.

    Headless + SSH + Version

    I turned on the SSH server using sudo raspi-config and the advanced options.

    The first thing I thought – Upgrade / Update to get the latest environment for the Raspberry Pi.  It’s a good start – always good to be up-to-date. Per the documentation, it may be necessary to run – sudo apt-get clean.

    sudo apt-get upgrade
    sudo apt-get update

    The raspi-config is another item that may need to be updated.   The update goes out and queries for the latest raspi-config, installs and relaunches the raspi-config.

    sudo raspi-config
    Select Option 8 - Advanced Options
    Selection Option A0 - Update
    Select Yes

    raspi-config
    raspi-config

    Next, I looked updated the Java version.  From reading the documentation, the next versions of the Pi are going to automatically include the Java installs.

    sudo apt-get update && sudo apt-get install oracle-java7-jdk

    Java Installation
    Java Installation

    I grabbed the Pi4J project jar files. The Pi4J is an opensource project which has some great details on PINOUT and boilerplate java code to access the underlying pin readouts.  I ran some quick code to get the latest snapshot installed.

    wget http://get.pi4j.com/download/pi4j-1.1-SNAPSHOT.deb
    sudo dpkg -i pi4j-1.1-SNAPSHOT.deb

    WGET
    WGET

    dpkg
    dpkg

    Pi4J is also installed on the Sonatype repositories and developed on GitHub.  Pi4J includes a script for managing updates.   It’s very convenient with the Apache 2.0 License.

    I was ready run a sample program – Get Sample, Compile and Run.

    wget https://raw.githubusercontent.com/Pi4J/pi4j/master/pi4j-example/src/main/java/ListenGpioExample.java
    pi4j ListenGpioExample.java
    pi4j -run ListenGpioExample

    First Sample
    First Sample

    Eventually, I am going to get to the point where I use the diagram from Pi4j.  The future efforts are going to take some time to get to – This step was the right step in the direction I want to go.  BBQ Champion.

  • Raspberry Pi – Initial Thoughts

    Thanks To Ada Fruit  I picked up a first version Raspberry Pi B+.   The experience brings me back to building my first computer and modifying it.

    I picked up an B+ Kit from Ada Fruit (based on the fact they have awesome tutorials).  I also picked up a Motor Controller, a Bread Board to hook up peripherals, and a Touch Screen Display.  The touch screen display wasn’t actually compatible with the kit I purchased.  Lesson learned – check the Male and Female connectors for the Displays and PIN (IN/OUT) counts.

    I laid out all the components on the bubble wrap, and I started assembling the components into one computer. The experience was rather like assembling a jigsaw puzzle.

    Easy As Pi
    Easy As Pi

    I used the 4G microSD card that came with the B+ kit.  I used it to immediately configure Debian and setup SSH. I got it on the wireless using the USB dongle for wireless, and I ran the updates for aptitude update and aptitude full-upgrade.  It’s nice that it persists all these changes.

    Now, that I am on the wireless, I can unplug the Raspberry Pi from the monitor, and connect to it via SSH.  It’s fantastic stuff. I am now going to work on my motor controller.

    Running Debian
    Running Debian

  • Setting up Db2 JDBC Access

    I have been working IBM Integration Broker 10.0.0.4. I found it hard to find concise documentation on setting up/creating a new provider

    mqsicreateconfigurableservice TESTNODE_cheetah -c JDBCProviders \
    -o DB2Two -n connectionUrlFormat -v \
    "jdbc:db2://[serverName]:[portNumber]/[databaseName]:user=[user];password=[password];"

    mqsisetdbparms TESTNODE_cheetah -n jdbc::employeeIdentity -u db2admin -p passw0rd1940!

    mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n securityIdentity -v employeeIdentity
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n portNumber -v 50000
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n serverName -v 9.32.18.166
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n databaseType -v DB2
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n databaseName -v SAMPLE
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n jarsURL -v c:\db2jars

    mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n type4DatasourceClassName -v com.ibm.db2.jcc.DB2XADataSource
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n type4DriverClassName -v com.ibm.db2.jcc.DB2Driver

    mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n databaseVersion -v 10.1
     mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n environmentParms -v ""

    mqsichangeproperties TESTNODE_cheetah -c JDBCProviders -o DB2Two -n jdbcProviderXASupport -v true


    Restart the Integration Server
